Tilt Turn

Tilt Turn windows and doors utilize the same profile system as our window systems. As a result, the seamless integration of windows provides a uniform appearance and customization beyond compare. Solar Innovations' tilt turn windows are a unique and functional European window, applicable in endless applications. While these windows have been manufactured for almost a hundred years, starting out in Europe in the early 1900′s, they have only recently become popular in the United States.

Operation: Tilt-Turn | Inswing and Outswing | Endless configurations possible

Primary Material: Aluminum

Width: Frame widths: 3-3/8" and 2-7/16"

Panel Size: Minimum panel size: 21"w x 30"h |  smaller panels may be available upon engineering approval | Maximum panel size up to 4' x 6' depending on hardware limitations

Framing Type: High performance sills available on select systems | LEED friendly system including recycled content

Hardware Included: Multiple handle styles and finishes | Zero-maintenance extruded aluminum hinges with stainless steel pins | Custom manufactured pulls and locks

Glazing: Designed to accommodate almost any glass infill from 1" to 1-3/8"

Performance: Air, water, structural, impact, acoustical and thermally tested options

Finish: AAMA 611 Class I anodized finishes: Clear, Dark Bronze | Standard AAMA 2605 powder coat finishes: Black, White, Sandstone, Natural Clay, Bronze and Hartford Green | Premium AAMA 2605 powder coat finishes | Custom Fluoropolymer (50% or 70%): AAMA 2605 | Custom Faux wood (Decoral) | Custom Dual finish — interior/exterior applications

Options: Wood veneer or metal cladding | Framed and cartridge retractable screen options | Mullions, decorative muntins, simulated divided lites (SDLs), interior and exterior grids

Grill Pattern Available: Arched Grid | Gothic Grid | Double Gothic Grid | Traditional Grid | Cross Grid | English Grid

Depth: Sash depth: 2-5/8"
