Multi Track Sliding Glass Door XX

Solar Innovations® Aluminum Sliding Glass Door Systems expand the view of any living space or commercial area. These systems can be used as external entryways or transitions between two interior spaces. Solar's acoustical sliding glass door systems are the ideal solution for projects that have high sound transmission class (STC) requirements. Although acoustic values are typically specific to the glazing selection, the construction of the frame can greatly influence the acoustical performance. Solar's acoustical sliding glass door systems allow for a 1 3⁄8-inch insulated glazing unit and are a standout product in the industry because they combine enhanced acoustical performance, superior thermal performance, and outstanding functionality.

Finish: AAMA 611 Class I anodized finishes: Clear, Dark Bronze | Standard AAMA 2605 powder coat finishes: Black, White, Sandstone, Natural Clay, Bronze and Hartford Green | Premium AAMA 2605 powder coat finishes | Custom Fluoropolymer (50% or 70%): AAMA 2605 | Custom Faux wood (Decoral) | Custom Dual finish — interior/exterior applications

Hardware Included: Custom manufactured operable hardware | Multiple hardware styles and finishes | Multiple sill designs, including high performance sill | Polymer and stainless steel rollers with precision bearings | 3" rollers for minimum panel width of 32" | 1-13/16" rollers for minimum panel width of 22" | Smaller panels may be available upon engineering approval

Model: Series SI8000

Performance: Weather-tight jamb interlock provides outstanding air and water performance

Glazing: Designed to accommodate almost any glazing infill including glass and solid-panel infills from 1/4" to 1-3/8"

Options: Matching fixed sidelites | Transoms possible on a project-by-project basis | True-radius and segmented-radius options available | Screen options: folding, sliding, retractable | Mullions, decorative muntins, simulated divided lites (SDLs), interior & exterior grids | No post 90° corners possible | Pocketing options: single or double sided | Factory installed sill drain tubes, if required | Motorized panels available

Panel Size: Minimum panel size: 22" wide |  smaller panels may be available upon engineering approval | Panel size up to 6' x 15' |  larger panel options may be available depending on application

Depth: G2: 1" | G3: 1-3/8", 1-1/4"

Primary Material: G2 Aluminum | G3 & G3 Lite Aluminum
