Modular Terrace Door Double

The G2 system utilizes a 2¼" thick frame made of durable, low maintenance aluminum. Terrace and French doors have a familiar operation with hinges being placed on the left or right side of the door frame. They can be designed to swing inward or outward and can be integrated into any Solar Innovations® system, or be installed in the rough opening of any structure. The unique mulling capabilities allow for modular construction and the seamless integration of transoms and sidelites.

Both Terrace and French door systems can include a thermal break, reducing the temperature transfer between the outdoors and indoors. Commercial systems can be designed for ADA compliance and equipped with standard push/pull panic, kick panel hardware, and locking mechanisms.

These door systems can be designed to meet or exceed regulations set forth in coastal areas.

Model: Series SI2000

Performance: Water performance up to 6.0psf, depending on sill choice, configuration, and water column | Structurally tested up to a design pressure of 50psf | Test results available upon request

Glazing: Designed to accommodate almost any monolithic, insulated, laminated, decorative, polycarbonate, or solid panel infill from 3/16" to 1-1/4"

Hardware Included: Zero-maintenance semi-concealed corrosion-proof extruded aluminum hinge with stainless steel pin | Panic hardware, door limiters & door closers | Multiple hardware styles & finishes | Multi-point locking hardware for added security

Finish: AAMA 611 Class I anodized finishes: Clear, Dark Bronze | Standard AAMA 2605 powder coat finishes: Black, White, Sandstone, Natural Clay, Bronze and Hartford Green | Premium AAMA 2605 powder coat finishes | Custom Fluoropolymer (50% or 70%): AAMA 2605 | Custom Faux wood (Decoral) | Custom Dual finish — interior/exterior applications

Options: Mullions, decorative muntins, simulated divided lites (SDLs), interior & exterior grids | Multiple screen options

Operation: Inswing or outswing

Primary Material: G2 Aluminum

Panel Size: Minimum panel size: 24" x 80" |  smaller panels considered windows by code but may be available upon engineering approval | Maximum panel size: 3-1/2' x 10' |  larger panel options may be available depending on application

Depth: G2: 2-1/4"
